Precautions for installing grooved pipe fittings

Precautions for installing grooved pipe fittings

When installing grooved pipe fittings, the following matters should also be noted to ensure safety and construction quality:

Groove drainage measures: The groove should be drained in time to prevent water accumulation and soaking. Once water accumulates, measures should be taken immediately to drain the water, remove the softened soil layer and fill it with sand and gravel.

Pipeline cutting quality control: The end face of the pipe cut should be perpendicular to the axis of the steel pipe, and there should be no burrs at the cut. Use a grinding wheel cutter or pipe cutter for cutting. Oxyacetylene is strictly prohibited. After cutting, use sandpaper, file or grinder to grind and remove burrs.

Support (hanging) frame setting: Set reasonable support (hanging) frames according to the characteristics of the pipeline to prevent axial displacement of the pipeline and joint leakage due to pressure and temperature changes.

Rubber ring installation: When installing grooved pipe fittings, tighten the bolts on both sides alternately, check whether the rubber sealing ring is wrinkled, and replace it in time if there is any problem.

Groove rolling process quality control: When rolling grooves, the groove depth should be controlled to avoid excessive depth or shallowness affecting the quality of the pipeline interface.

Cleaning and inspection: Before installation, the pipe fittings and grooves must be cleaned, checked for impurities or damage, and all pipe fittings and accessories must be compatible and installed correctly.

Maintenance and care: After installation, regularly check whether the connection is tight, clean and lubricated to ensure the long-term performance of the pipeline system.

Civilized construction: During the construction process, attention should be paid to protecting the finished product, avoiding the application of inappropriate external force, preventing mechanical damage and leaving hidden dangers.

By following the above precautions, the installation quality and safety of grooved pipe fittings can be effectively ensured.
